Features:
IPS display technology delivers wider viewing angles and sharp contrast at twice the resolution of traditional displays
Smart and intuitive LightHouse 3 OS makes navigating easy
Uncluttered interface that can be easily personalized for your style of navigating
Next-generation, high-performance 10 Hz GPS/GNSS receiver with 4X increased sensitivity for accurate positioning
Support for the best charts from Navionics and LightHouse Raster and Vector Charts sourced from leading map makers like NV Digital, Blue Latitude, and more
Quantum CHIRP radar ready - Superior solid state CHIRP radar delivers no compromise performance on long and extremely short ranges
Marine audio control - Control NMEA2000 compatible marine audio systems
Ready to network, with Raynet ethernet and NMEA2000
Connect multiple Axiom displays or expand with Quantum, HD radar, IP cameras, engine gauges, autopilots, instruments and more
Built-in Wi-Fi for streaming and control right from your smartphone or tablet
Sync Axiom's waypoints, routes, and charts with Navionics mobile apps
Includes Lighthouse Charts North America
Specifications:
Display Type: Multitouch with HydroTough™ rugged hydrophobic coating
Brightness: 1,500 nits
Viewing Angle: 85° Top, Bottom, Left, Right
Dimensions (W x H x D): 7.92" x 5.24" x 3.0"
Mounting options: Surface, Flush, Trunnion, (Front installation bracket available)
Waterproof rating: IPX6/IPX7
Operating temperature range: -13° F to 131° F
Storage temperature range: -22° F to 158° F
Sensors
GNSS/GPS: Built-in GNSS Receiver: GPS/GLONASS/Galileo/Beidou - 10Hz 28 Channel - Future software update required
External sensor: Yes - CP100, CP200, CP370, CP470, CP570, RVX1000 via RayNet
Radar: Yes - Quantum, Digital, HD Color/Super HD Color and Magnum Radars
AIS: Yes - NMEA2000 compatible
Autopilot control: Yes - Evolution Autopilot
Thermal night vision: Yes FLIR AX8, M232, M300 Series, M400, M500
Video/Camera: Compatible with CAM210IP, CAM220IP (Up to 10 IP network cameras)
Weather: GRIB View - Free GRIB viewer and Theyr Ltd Subscription | SiriusXM - N. America Only
Audio: NMEA2000/Bluetooth speaker controls/Optional SiriusXM Audio
Digital switching: Yes - Empirbus & C-Zone compatible
Remote control: Yes - Optional RMK-10 (A80438)
Networking
Ethernet: 1 x 10/100 Mbit/s Network (RayNet)
NMEA0183: No
NMEA2000: NMEA2000 via DeviceNet port. SeaTalkNG compatible using an optional adapter
SeaTalkNG: Requires DeviceNet Female (F) adaptor cable (A06079 120mm adaptor included in box)
USB: 1x USB microAB
Wi-Fi: 802.11 a/b/g/n
BlueTooth: v4.0
Navigation
Cartography: Lighthouse Charts, Navionics, and C-MAP compatible
Waypoint/Routes/Tracks: 10,000 wpts/200 wpt groups/150 rts - 250 wpt max/16 tracks - 10,000 max trk pts
Memory
Internal memory: 16 GB Solid State
External memory: 1x MicroSD Card Slot
Languages: 24
