Features:
Get built-in Ultra High-Definition SideVu and ClearVu scanning sonars with vivid, high-contrast color palettes to help distinguish fish from structure
With its added processing power and new slimline design featuring edge-to-edge glass and a smaller unit footprint
New higher-resolution IPS displays offer improved sunlight readability and visibility from any angle
Experience unparalleled coverage and detail with built-in Garmin Navionics+ or BlueChart/LakeVu G3
View laylines, race start line guidance, enhanced wind rose, heading and course-over-ground lines, true wind data fields and tide/current/time slider, wind angle, set and drift, wind speed, polars and more
Use the polar table to see key data, including how fast you should go at a certain wind angle and speed — so you know whether you need to adjust sail trim
If you have multiple compatible Garmin devices on your boat, you can share information — such as maps, user data, radar and IP camera video — among them
Connect to compatible autopilots, digital switching, weather, Fusion-Link audio system, media, VHF, AIS and more from one screen
Built-in Wi-Fi connectivity pairs with the free all-in-one mobile app for access to the OneChart feature and more
Now you can connect your chartplotter to different kinds of engines, including select Yamaha engines
Specifications:
Dimensions: 7.6" x 5.5" x 2.9" (19.2 x 14.0 x 7.4 cm)
Input: Touchscreen
Display Size: 6.1" x 3.5"; 7.0" diagonal (15.4 x 9.1 cm; 17.8 cm diagonal)
Display Resolution: 1024 x 600 pixels
Display Type: WSVGA
Weight: 2.8 lbs (1.3 kg)
Waterproof: IPX7
Smart Mode Compatible
AIS
DSC
Supports Fusion-Link Compatible Radios
GSD Black Box Sonar Support
GCV Black Box Sonar Support
Activecaptain Compatible: yes
Grid (Garmin Remote Input Device) Compatible
Wireless Remote Compatible
Sailing Features
Spoken Audio Alerts
Onehelm Support
Sensors:
Has Built-In Receiver
Receiver: 10 Hz
NMEA 2000 Compatible
NMEA 0183 Compatible
GPS
GLONASS
Galileo
Supports WAAS
Sonar:
Displays Sonar
Power Output: 1 kW
Traditional Sonar (Dual Frequency/Beam): built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)
Clearvu: built-in 260/455/800/1000/1200 kHz
Sidevu: built-in 260/455/800/1000/1200 kHz
Panoptix Sonar
Livescope
Connections:
NMEA 2000 Ports: 1
Connections NMEA0183 Input Ports: 1
NMEA 0183 Input (Tx) Ports: 1
Video Input Ports: 1 (BNC composite)
J1939 Ports: 1
Garmin Marine Network Ports: 1
12-Pin Transducer Ports: 1
Usb Ports
Bnc External GPS Antenna Port
Bluetooth Pairing
Ant+ (Connectivity)
Garmin Wi-Fi Network (Local Connection)
